Vous trouverez ici toutes les pièces et dessins disponibles du 'Hikoki TED-210S'. De là, vous pouvez commander directement toutes les pièces souhaitées. De nombreuses pièces doivent être commandées auprès du fabricant, selon la marque, cela prend une à quatre semaines. Toutes les informations dont nous disposons se trouvent sur notre site Web, nous ne pouvons pas vous conseiller sur ce dont vous avez besoin, pour cela vous devrez retourner la machine pour réparation. Veuillez noter ce qui suit lors de la commande:
Dessins des Hikoki TED-210S
Liste de pièces de rechange des Hikoki TED-210S
| Pos. | Description | Prix hors TVA | Prix TTC | |
| Les prix affichés incluent la TVA | ||||
| Spark Plug Cap Ass'y (old 157-06500-91) | ||||
| 1 | 6687476@1417 | 4.45 | 5.34 | |
| Bougie Rcj8y | ||||
| 2 | 6699328@1417 | 3.30 | 3.96 | |
| Cylinder Set (old 001-0650a-90) | ||||
| 3 | 6685480@1417 | 40.24 | 48.28 | |
| Pas d'informations disponibles, non commandable | ||||
| 4 | 6684668@1417 | |||
| Cylinder Gasket (old 017-06500-20) | ||||
| 5 | 6685744@1417 | 1.15 | 1.38 | |
| Piston Ring (old 041-00601-21/ 6686117) | ||||
| 6 | 6686118@1417 | 4.45 | 5.34 | |
| Piston Set (old 030-0650a-90) | ||||
| 7 | 6685892@1417 | 20.11 | 24.14 | |
| Zuiger Pin | ||||
| 8 | 6696944@1417 | 3.33 | 3.99 | |
| Piston Pin Circlip (old 039-01620-20) | ||||
| 9 | 6686028@1417 | 1.15 | 1.38 | |
| Crank Shaft Comp. (old 046-06500-80) | ||||
| 10 | 6686205@1417 | 72.30 | 86.76 | |
| Ignition Coil Ass'y (old 153-21532-92 & 6687694) | ||||
| 11 | 6695927@1417 | 34.19 | 41.02 | |
| Vis Ø4x18 Till H124040 | ||||
| 12 | 6684599@1417 | 2.15 | 2.58 | |
| Insulator Tube 50l (old 250-06500-20) | ||||
| 13 | 6684597@1417 | 2.15 | 2.58 | |
| Cord (old 178-06500-80) | ||||
| 14 | 6687866@1417 | 3.30 | 3.96 | |
| Bobine | ||||
| 15 | 6695939@1417 | 38.26 | 45.92 | |
| Crankcase Ass'y (old 072-06502-90) | ||||
| 21 | 6686575@1417 | 36.58 | 43.89 | |
| Crank Case Gasket (old 090-06500-20) | ||||
| 22 | 6686720@1417 | 1.15 | 1.38 | |
| Olie Keerring | ||||
| 23 | 6684607@1417 | 4.29 | 5.14 | |
| Roulement à billes | ||||
| 24 | 6684608@1417 | 3.80 | 4.56 | |
| Gear Shaft Shim 0.20 (oud 330-00200-23) | ||||
| 25 | 6684604@1417 | 2.15 | 2.58 | |
| Gear Shaft Shim 0.30 (oud 330-00200-24) | ||||
| 25 | 6684605@1417 | 2.15 | 2.58 | |
| Gear Shaft Shim 0.10 (old 330-00200-21) | ||||
| 25 | 6689177@1417 | 1.15 | 1.38 | |
| Gear Shaft Shim 0.15 (old 330-00200-22) | ||||
| 25 | 6689178@1417 | 1.15 | 1.38 | |
| Caoutchouc anti-vibrateur | ||||
| 26 | 6691822@1417 | 1.15 | 1.38 | |
| Hex. Socket Hd. Bolt M5x30 S (old 994-61050-304) | ||||
| 27 | 6684786@1417 | 2.15 | 2.58 | |
| Vliegwiel | ||||
| 28 | 6687389@1417 | 26.16 | 31.40 | |
| Ring M8 (old 992-01080-011) | ||||
| 29 | 6684611@1417 | 2.15 | 2.58 | |
| Bague | ||||
| 30 | 6684971@1417 | 1.04 | 1.24 | |
| Nut M8 (old 991-01080-011/327325/332299/726603) | ||||
| 31 | 6684612@1417 | 2.15 | 2.58 | |
| Pas d'informations disponibles, non commandable | ||||
| 32 | 6686778@1417 | |||
| Intake Pipe Gasket (old 403-06500-20) | ||||
| 41 | 6689891@1417 | 1.15 | 1.38 | |
| Carb. Insulator Set,spare (old 404-06500-90) | ||||
| 42 | 6689966@1417 | 6.93 | 8.31 | |
| Hex. Hole Bolt 5x25ws (old 994-64050-254/6696513) | ||||
| 43 | 6695515@1417 | 1.15 | 1.38 | |
| Carburetor Gasket (old 402-06500-20) | ||||
| 44 | 6689839@1417 | 1.15 | 1.38 | |
| O-ring P-15 | ||||
| 45 | 6698966@1417 | 1.04 | 1.24 | |
| Cleaner Body Comp. (old 423-06500-81/6690118) For | ||||
| 46 | 6690119@1417 | 4.45 | 5.34 | |
| Collar 7.5 (old 470-06500-20) | ||||
| 47 | 6690804@1417 | 1.15 | 1.38 | |
| Choke Valve (old 528-06500-20) | ||||
| 48 | 6691272@1417 | 2.31 | 2.78 | |
| Pas d'informations disponibles, non commandable | ||||
| 49 | 6684658@1417 | |||
| Blow Over Check Board (old 476-01700-20/790189) | ||||
| 50 | 6690843@1417 | 1.15 | 1.38 | |
| Ring (oud 992-10050-012) | ||||
| 51 | 6684662@1417 | 2.15 | 2.58 | |
| Screw M5x60 (oud 990-11050-602) | ||||
| 52 | 6684660@1417 | 2.15 | 2.58 | |
| Reinigingsspons | ||||
| 53 | 6690364@1417 | 1.15 | 1.38 | |
| Luchtfilterkap | ||||
| 54 | 6690415@1417 | 5.28 | 6.33 | |
| Special Screw (old 380-0637c-20) | ||||
| 55 | 6689737@1417 | 1.15 | 1.38 | |
| Plus disponible, pas de remplacement | ||||
| 56 | 6690482@1417 | |||
| Carburateurset | ||||
| 56A | 6690487@1417 | 72.30 | 86.76 | |
| Shield Tube Ass'y (old 223-06500-90) | ||||
| 57 | 6685247@1417 | 2.31 | 2.78 | |
| Clip D6 (old 680-00070-20) | ||||
| 58 | 6685198@1417 | 1.15 | 1.38 | |
| Pas d'informations disponibles, non commandable | ||||
| 59 | 6684620@1417 | |||
| Tank White (old 591-0664a-20) | ||||
| 60 | 6691582@1417 | 9.74 | 11.68 | |
| Collar 5.8 (old 659-00801-20) | ||||
| 61 | 6692244@1417 | 1.15 | 1.38 | |
| Hex. Hole Bolt 5x18ps (old 994-63050-185) | ||||
| 62 | 6695505@1417 | 1.15 | 1.38 | |
| Swivel Cap (old 560-07120-21/6684628) | ||||
| 63 | 6691337@1417 | 1.15 | 1.38 | |
| Tank Cap D Ass'y, Black (old 595-06516-90 & 669171 | ||||
| 64 | 6691763@1417 | 7.59 | 9.10 | |
| Priming Pump Comp. (old 442-25143-80) | ||||
| 65 | 6685139@1417 | 5.94 | 7.12 | |
| Fuel Pipe 2.5x4x80 (old 700-02504-08) | ||||
| 66 | 6692347@1417 | 1.15 | 1.38 | |
| Fuel Pipe 2.5x4x70 (old 700-02504-07) | ||||
| 67 | 6692346@1417 | 1.15 | 1.38 | |
| Return Grommet (old 6684627) | ||||
| 68 | 6697846@1417 | 1.04 | 1.24 | |
| Pas d'informations disponibles, non commandable | ||||
| 69 | 6684625@1417 | |||
| Muffler Protector (old 738-06500-20) | ||||
| 81 | 6692795@1417 | 6.93 | 8.31 | |
| Muffler Gasket (old 737-06500-20) | ||||
| 82 | 6692744@1417 | 1.15 | 1.38 | |
| Warmteschild | ||||
| 83 | 6687252@1417 | 2.31 | 2.78 | |
| Pas d'informations disponibles, non commandable | ||||
| 84 | 6692480@1417 | |||
| Bague | ||||
| 85 | 6684661@1417 | 2.15 | 2.58 | |
| Hex. Socket Hd. Bolt M5x50 (old 990-51050-503) | ||||
| 86 | 6685114@1417 | 1.15 | 1.38 | |
| Grommet (old 203-0604a-20) | ||||
| 87 | 6688050@1417 | 1.15 | 1.38 | |
| Hex.hole Bolt 4x18ps (old 994-63040-184) | ||||
| 88 | 6695502@1417 | 1.15 | 1.38 | |
| Slipkoppeling Kompleet | ||||
| 89 | 6688494@1417 | 9.74 | 11.68 | |
| Tapping Screw D4.5x16 (old 990-72045-164/790451) | ||||
| 90 | 6684636@1417 | 2.15 | 2.58 | |
| Bolt 4x12ps (old 994-25040-128) | ||||
| 91 | 6695441@1417 | 1.15 | 1.38 | |
| Enveloppe De Ventilateur | ||||
| 92 | 6687014@1417 | 16.94 | 20.32 | |
| Starter Rope Reel (old 774-0651h-20) | ||||
| 93 | 6693072@1417 | 5.11 | 6.14 | |
| Cam Plate (old 759-0651h-20) | ||||
| 94 | 6684678@1417 | 6.44 | 7.72 | |
| Dumper Spring (old 758-0651h-20) | ||||
| 95 | 6684677@1417 | 8.58 | 10.29 | |
| Recoil Spring (old 780-06097-20/6697591) | ||||
| 96 | 6684675@1417 | 11.55 | 13.86 | |
| SET SCREW (OLD 839-03045-20) | ||||
| 97 | 6684679@1417 | 2.15 | 2.58 | |
| Rope 3x890 (old 783-0651h-20) | ||||
| 98 | 6693172@1417 | 2.31 | 2.78 | |
| Starthendel | ||||
| 99 | 6693237@1417 | 1.15 | 1.38 | |
| Starter Pulley Ass'y (old 798-0651h-90) | ||||
| 100 | 6684681@1417 | 13.20 | 15.84 | |
| Deflector (old 132-06602-20) | ||||
| 101 | 6687209@1417 | 6.44 | 7.72 | |
| Starter Pawl (old 788-0651h-20) | ||||
| 102 | 6684685@1417 | 4.29 | 5.14 | |
| Starter Pawl Spring (old 790-06097-20) | ||||
| 103 | 6684684@1417 | 4.29 | 5.14 | |
| D4e Retaining Ring (old 993-55040-001) | ||||
| 104 | 6685101@1417 | 1.15 | 1.38 | |
| Plate (old 795-04063-20) | ||||
| 105 | 6685189@1417 | 1.15 | 1.38 | |
| Throttle Set Screw (old 548-25140-20) | ||||
| 121 | 6684698@1417 | 4.29 | 5.14 | |
| Swivel (oud 539-25120-20) | ||||
| 122 | 6684697@1417 | 6.44 | 7.72 | |
| Stop Ring (oud 489-25100-20) | ||||
| 123 | 6684696@1417 | 2.15 | 2.58 | |
| Throttle Valve Comp. (old 488-25145-80) | ||||
| 124 | 6684883@1417 | 18.75 | 22.50 | |
| O-RING (OUD 550-25100-20) | ||||
| 125 | 6684695@1417 | 4.29 | 5.14 | |
| Main Jet #40 (old 599-2000w-40) | ||||
| 126 | 6691845@1417 | 4.45 | 5.34 | |
| Main Jet #34.5 (old 599-200bw-34) | ||||
| 126A | 6691888@1417 | 6.28 | 7.53 | |
| Pump Gasket (old 577-25100-20) | ||||
| 127 | 6691457@1417 | 7.10 | 8.52 | |
| Pump Diaphragm (old 576-25100-20 & 6696325) | ||||
| 128 | 6684693@1417 | 8.58 | 10.29 | |
| Inlet Screen (oud 578-25007-20) | ||||
| 129 | 6684700@1417 | 4.29 | 5.14 | |
| Pump Body Comp. (old 575-25147-80/6691428) | ||||
| 130 | 6691430@1417 | 36.15 | 43.38 | |
| Diaphragm Packing (old 475-25038-20) | ||||
| 131 | 6685220@1417 | 2.31 | 2.78 | |
| Metering Diaphragm Comp. (old 474-25001-80/6690826 | ||||
| 132 | 6690827@1417 | 11.71 | 14.06 | |
| Diaphragm Cover (old 476-25004-20) | ||||
| 133 | 6685222@1417 | 4.45 | 5.34 | |
| Set Screw (old 548-25101-20) | ||||
| 134 | 6691312@1417 | 1.15 | 1.38 | |
| Gear Case A Comp. (old 002-32182-80) | ||||
| 151 | 6685578@1417 | 28.14 | 33.76 | |
| Plus disponible, pas de remplacement | ||||
| 152 | 6685593@1417 | |||
| Plus disponible, pas de remplacement | ||||
| 153 | 6688197@1417 | |||
| Gear 2 (old 012-32120-20) | ||||
| 154 | 6685655@1417 | 30.25 | 36.30 | |
| Pas d'informations disponibles, non commandable | ||||
| 155A | 6685702@1417 | |||
| Wood-ruff Key 3x10x3.7 (old 068-00300-20) | ||||
| 156 | 6686454@1417 | 1.15 | 1.38 | |
| Roulement à billes | ||||
| 157 | 6695532@1417 | 6.60 | 7.92 | |
| Roulement à billes | ||||
| 158 | 6684608@1417 | 3.80 | 4.56 | |
| Stop Ring C-12 Outer | ||||
| 159 | 6684664@1417 | 2.15 | 2.58 | |
| Gear 4 (old 018-32120-21) | ||||
| 160A | 6685785@1417 | 24.20 | 29.04 | |
| Roulement à billes | ||||
| 161 | 6695587@1417 | 14.21 | 17.06 | |
| Washer C 5.0 (old 040-32120-20) | ||||
| 162 | 6686065@1417 | 3.30 | 3.96 | |
| Roulement à billes | ||||
| 163 | 6695559@1417 | 6.44 | 7.72 | |
| Stop Ring C-35, Inner (old 993-51035-002/791059) | ||||
| 164 | 6695296@1417 | 1.15 | 1.38 | |
| Wood-ruff Key 3x13x5 (old 068-01006-20) | ||||
| 165 | 6686455@1417 | 1.15 | 1.38 | |
| Drive Shaft (old 022-32120-20) | ||||
| 166 | 6685822@1417 | 13.86 | 16.64 | |
| Plus Bolt 6x30 (old 990-23060-301) | ||||
| 167 | 6695022@1417 | 1.15 | 1.38 | |
| Pas d'informations disponibles, non commandable | ||||
| 168 | 6684792@1417 | |||
| Bague | ||||
| 169 | 6695219@1417 | 1.15 | 1.38 | |
| Screw 5x18/s (old 994-14050-181) | ||||
| 170 | 6695339@1417 | 1.15 | 1.38 | |
| Bague | ||||
| 171 | 6695206@1417 | 1.15 | 1.38 | |
| Pas d'informations disponibles, non commandable | ||||
| 172 | 6688233@1417 | |||
| GREASE NIPPLE COMP. (OLD 300-32250-80) | ||||
| 173 | 6688643@1417 | 1.15 | 1.38 | |
| Handle Comp.a (old 258-3210a-82) | ||||
| 191 | 6688369@1417 | 36.15 | 43.38 | |
| Handle Grip A (old 165-33130-20/6691224) | ||||
| 192 | 6687624@1417 | 5.78 | 6.93 | |
| Throttle Lever (old 101-32120-20) | ||||
| 193 | 6686799@1417 | 2.31 | 2.78 | |
| Screw 5x25 (old 990-11050-251/6694895) | ||||
| 194 | 6694896@1417 | 1.15 | 1.38 | |
| Hex. Nut 5 (old 991-01050-011) | ||||
| 195 | 6684965@1417 | 1.04 | 1.24 | |
| Cord Clamp (old 198-33130-20) | ||||
| 196 | 6688015@1417 | 1.15 | 1.38 | |
| Plus Bolt 6x16 (old 990-23060-161) | ||||
| 197 | 6695019@1417 | 1.15 | 1.38 | |
| Bague | ||||
| 198 | 6695219@1417 | 1.15 | 1.38 | |
| Handle Comp. B (old 259-3210a-80) | ||||
| 199 | 6688372@1417 | 13.20 | 15.84 | |
| Handle Grip (old 055-32130-20) | ||||
| 200 | 6686350@1417 | 5.28 | 6.33 | |
| Bague | ||||
| 201 | 6695225@1417 | 1.15 | 1.38 | |
| Stop Switch Comp. (old 156-3210a-80/6687757) | ||||
| 202 | 6687431@1417 | 8.41 | 10.10 | |
| Stop Button Mark (old 925-33176-20) | ||||
| 203 | 6694589@1417 | 2.31 | 2.78 | |
| Button Stop (old 258-11650-20) | ||||
| 204 | 6688366@1417 | 1.15 | 1.38 | |
| Screw 3x10 (old 994-31030-101) | ||||
| 205 | 6684913@1417 | 2.15 | 2.58 | |
| Gaskabel | ||||
| 206 | 6693908@1417 | 4.45 | 5.34 | |
| Pas d'informations disponibles, non commandable | ||||
| 207 | 6687532@1417 | |||
| Chuck Handle Holder (old 155-3210a-20) | ||||
| 208 | 6687420@1417 | 4.45 | 5.34 | |
| Chuck Handle Set (old 059-32120-91) | ||||
| 501 | 6686372@1417 | 44.31 | 53.18 | |
| Drill Chuck Ass'y (old 060-32120-91) | ||||
| 502 | 6686377@1417 | 80.31 | 96.38 | |
| Chuck Handle Comp. (old 061-32120-81) | ||||
| 503 | 6686410@1417 | 4.45 | 5.34 | |
| Combi Box Spanner 13x19 Plus (old 829-20000-80) | ||||
| 504 | 6684979@1417 | 4.29 | 5.14 | |
